Truss Bridges: Beam Bridges With Braces
Travel around the world, and you'll encounter dozens of variations on your standard beam bridge. The key differences, however, all come down to the design, location and composition of the truss.
During the early Industrial Revolution, beam bridge construction in the United States was rapidly developing. Engineers gave many different truss designs a whirl in an attempt to perfect it. Their efforts weren't for naught. Wooden bridges were soon replaced by iron models or wood-and-iron combinations.
All these different truss patterns also factored into how beam bridges were being built. Some takes featured a through truss above the bridge, while others boasted a deck truss beneath the bridge.
A single beam spanning any distance undergoes compression and tension. The very top of the beam gets the most compression, and the very bottom of the beam experiences the most tension. The middle of the beam experiences very little compression or tension. This is why we have I-beams, which provide more material on the tops and bottoms of beams to better handle the forces of compression and tension.
And there's another reason why a truss is more rigid than a single beam: A truss has the ability to dissipate a load through the truss work. The design of a truss, which is usually a variant of a triangle, creates both a very rigid structure and one that transfers the load from a single point to a considerably wider area.
While truss bridges are largely a product of the Industrial Revolution, our next example, the arch, dates back much further in time. Grab your sword and sandals, because we're about to go Roman.
BATS: The Basics of Bridge Design
If you're going to build a bridge, you'll need some help from BATS -- not the furry, winged mammals that so often live beneath bridges, but the key structural components of bridge construction:beams, arches, trusses andsuspensions.
Various combinations of these four technologies allow for numerous bridge designs, ranging from simple beam bridges, arch bridges, truss bridgesand suspension bridges to more complex variations, such as the picturedside-spar cable-stayed bridge. For all its 21st century complexity, the side-spar design is based on suspension principles first used some two centuries earlier.
The key differences between these four bridge types comes down to the lengths they can cross in a singlespan, which is the distance between two bridge supports, the physical braces that connect the bridge to the surface below. Bridge supports may take the form of columns, towers or even the walls of a canyon.
Modern beam bridges, for instance, are likely to span up to 200 feet (60 meters), while modern arch bridges can safely cross 800-1,000 feet (240-300 meters). Suspension bridges are capable of extending from 2,000-7,000 feet (610-2,134 meters).
Regardless of the structure, every bridge must stand strong under the two important forces we'll talk about
The Beam Bridge
Bridge building doesn't get any simpler than this. In order to build a beam bridge (also known as a girder bridge), all you need is a rigid horizontal structure (a beam) and two supports, one at each end, to rest it on. These components directly support the downward weight of the bridge and any traffic traveling over it.
However, in supporting weight, the bream bridge endures both compressional and tensional stress. In order to understand these forces, let's use a simple model.
If you were to take a two-by-four and lay it across two empty milk crates, you'd have yourself a crude beam bridge. Now if you were to place a heavy weight in the middle of it, the two-by-four would bend. The top side would bend in under the force of compression, and the bottom side would bend out under the force of tension. Add enough weight and the two-by-four would eventually break. The top side would buckle and the bottom side would snap.
Many beam bridges use concrete or steel beams to handle the load. The size of the beam, and in particular the height of the beam, controls the distance that the beam can span. By increasing the height of the beam, the beam has more material to dissipate the tension. To create very tall beams, bridge designers add supporting latticework, or a truss, to the bridge's beam. This support truss adds rigidity to the existing beam, greatly increasing its ability to dissipate the compression and tension. Once the beam begins to compress, the force spreads through the truss.
Yet even with a truss, a beam bridge is only good for a limited distance. To reach across a greater length, you have to build a bigger truss until you eventually reach the point at which the truss can't support the bridge's own weight. Brace yourself for some serious stats on truss bridges on the next page.
The Arch Bridge
After more than 2,000 years of architectural use, the arch continues to feature prominently in bridge designs and with good reason: Its semicircular structure elegantly distributes compression through its entire form and diverts weight onto its two abutments, the components of the bridge that directly take on pressure.
Tensional force in arch bridges, on the other hand is virtually negligible. The natural curve of the arch and its ability to dissipate the force outward greatly reduces the effects of tension on the underside of the arch.
But as with beams and trusses, even the mighty arch can't outrun physics forever. The greater the degree of curvature (the larger the semicircle of the arch), the greater the effects of tension on the underside of the bridge. Build a big enough arch, and tension will eventually overtake the support structure's natural strength.
While there's a fair amount of cosmetic variety in arch bridge construction, the basic structure doesn't change. There are, for example, Roman, Baroque and Renaissance arches, all of which are architecturally different but structurally the same.
It is the arch itself that gives its namesake bridge its strength. In fact, an arch made of stone doesn't even need mortar. The ancient Romans built arch bridges and aqueducts that are still standing today. The tricky part, however is building the arch, as the two converging parts of the structure have no structural integrity until they meet in the middle. As such, additional scaffolding or support systems are typically needed.
Modern materials such as steel and prestressed concrete allow us to build far larger arches than the ancient Romans did. Modern arches typically span between 200 and 800 feet (61 and 244 meters), but West Virginia's New River Gorge Bridge measures an impressive 1,700 feet (518 meters) [source: NOVA].
The Suspension Bridge
As the name implies, suspension bridges, like the Golden Gate Bridge or Brooklyn Bridge, suspend the roadway by cables, ropes or chains from two tall towers. These towers support the majority of the weight as compression pushes down on the suspension bridge's deck and then travels up the cables, ropes or chains to transfer compression to the towers. The towers then dissipate the compression directly into the earth.
The supporting cables, on the other hand, receive the bridge's tension forces. These cables run horizontally between the two far-flung anchorages. Bridge anchorages are essentially solid rock or massive concrete blocks in which the bridge is grounded. Tensional force passes to the anchorages and into the ground.
In addition to the cables, almost all suspension bridges feature a supporting truss system beneath the bridge deck called a deck truss. This helps to stiffen the deck and reduce the tendency of the roadway to sway and ripple.
Suspension bridges can easily cross distances between 2,000 and 7,000 feet (610 and 2,134 meters), enabling them to span distances beyond the scope of other bridge designs. Given the complexity of their design and the materials needed to build them, however, they're often the most costly bridge option as well.
But not every suspension bridge is an engineering marvel of modern steel. In fact, the earliest ones were made of twisted grass. When Spanish conquistadors made their way into Peru in 1532, they discovered anIncan empire connected by hundreds of suspension bridges, achieving spans of more than 150 feet (46 meters) across deep mountain gorges. Europe, on the other hand, wouldn't see its first suspension bridge until nearly 300 years later [source: Foer].
Of course, suspension bridges made from twisted grass don't last that long, requiring continual replacement to ensure safe travel across the gap. Today, only one such bridge remains, measuring 90 feet (27 meters) in the Andes.
What's next? Hint: You'll have to stay (that's a hint!) around to find out.
At first glance, the cable-stayed bridgemay look like just a variant of the suspension bridge, but don't let their similar towers and hanging roadways fool you. Cable-stayed bridges differ from their suspension predecessors in that they don't require anchorages, nor do they need two towers. Instead, the cables run from the roadway up to a single tower that alone bears the weight.
The tower of a cable-stayed bridge is responsible for absorbing and dealing with compressional forces. The cables attach to the roadway in various ways. For example, in a radial pattern, cables extend from several points on the road to a single point at the tower, like numerous fishing lines attached to a single pole. In a parallel pattern, the cables attach to both the roadway and the tower at several separate points.
Engineers constructed the first cable-stayed bridges in Europe following the close of World War II, but the basic design dates back to the 16th century and Croatian inventor Faust Vrancic. A contemporary of astronomers Tycho Brache and Johannes Kepler, Vrancic produced the first known sketch of a cable-stayed bridge in his book "Machinae Novae."
Today, cable-stayed bridges are a popular choice as they offer all the advantages of a suspension bridge but at a lesser cost for spans of 500 to 2,800 feet (152 to 853 meters). They require less steel cable, are faster to build and incorporate more precast concrete sections.
Not all bridges requires great hunks of steel and concrete though. Sometimes a tree root or two will do the trick.
More Bridge Forces: Resonance
You can think of resonance as the vibrational equivalence of a snowball rolling down a hill and becoming anavalanche. It begins as a relatively small, periodic stimulus of a mechanical system, such as wind buffeting a bridge. These vibrations, however, are more or less in harmony with the bridge's natural vibrations. If unchecked, the vibration can increase drastically, sending destructive, resonant vibrations traveling through a bridge in the form of torsional waves.
The most noteworthy example of resonance occurred in 1940, when resonant vibrations destroyed the Tacoma Narrows Bridge in Washington. The incident was especially shocking at the time as the structure was designed to withstand winds of up to 120 miles (193 kilometers) per hour and collapsed in a mere 40-mile (64-kilometer) wind.
Close examination of the situation suggested that the bridge's deck-stiffening truss was insufficient for the span, but this alone couldn't bring such a structure down. As it turned out, the wind that day was at just the right speed and hit the bridge at just the right angle to set off the deadly vibration. Continued winds increased the vibrations until the waves grew so large and violent that they broke the bridge apart. The effect is similar to that of a singer shattering a glass with her voice.
Wind isn't the only potential threat, however. When an army marches across a bridge, the soldiers often "break step" so that their rhythmic marching will start resonating throughout the bridge. A sufficiently large army marching at just the right cadence could set the deadly vibration into motion.
In order to mitigate fully the resonance effect in a bridge, engineers incorporate dampeners into the bridge design to interrupt the resonant waves and prevent them from growing.
Another way to halt resonance is to give it less room to run wild. If a bridge boasts a solid roadway, then a resonant wave can easily travel the length of the bridge and wreak havoc. But if a bridge roadway is made up of different sections with overlapping plates, then the movement of one section merely transfers to another via the plates, generating friction. The trick is to create enough friction to change the frequency of the resonant wave. Changing the frequency prevents the wave from building.
We are a species of bridge builders. Since time out of mind, humans have engineered structures to surmount obstacles, such as, say, Jiaozhou Bay. The body of water is now home to a 26.4-mile (42.5-kilometer) bridge that links the busy Chinese port city of Quingdao to the Chinese suburb of Huangdou.
We've tamed steel, stone, lumber and even living vegetation, all in an effort to reach the places, people and things we desire.
Although the concept itself is as simple as felling a tree across a creek, bridge design and construction entails serious ingenuity. Artists, architects and engineers pour vast resources into bridge construction and, in doing so, reshape the very environment in which we live.
As a result, we inhabit a planet of bridges, some as ancient as Greece's 3,000-year-old Arkadiko bridge or as unchanged as India's 500-year-old Meghalaya living bridges, which are coaxed into existence from growing tree roots (more on that later). Countless others have fallen into the ravines and rivers they span, as humans continue to tackle ever more ambitious bridges and construction.
In this article, we'll get to know the bridges we so often take for granted (we literally walk and drive all over them), as well as the designs that make them possible. We'll look at the fundamental principles of bridge engineering, the different types and how we attempt to thwart the physical forces and natural phenomena that perpetually threaten to destroy the world's bridges.
